Skycut F3550 Double Head Auto Contour Flatbed Cutting Plotter With Vacuum Adsorbing Built-in Camera for Reflective Film

₹224,200.00

The compact tabletop flatbed cutting machine, the F3550 is ideal for packaging prototypes, cardboard samples, various foam materials, sticker sheets, and craft projects. Offering dual-head operation with strong vacuum suction and precision in cutting and creasing, it is ideal for studios, small manufacturing units, and prototyping environments.

Quantity

Specification Model F3550 Max cutting size 350*500mm Contour cutting size 350*500mm Working pattern Vacuum adsorption Auto contour cut Camera(automatically contour cutting) Control panel 5-inch touch screen X-axis and Y-axis motors Servo motor Z-axis Motor Voice Coil Motor Max force 800g Number of heads 2 Tool type 45°/ 60° Cutting precision +/-0.01mm Repeat precision 0.025 mm Max moving speed 1200mm/s Max cutting speed 1200mm/S Connector interface USB/WIFl//Ethernet Working environment +5°C-+35°C Machine size/weight 940*690*290mm/35KG Fan size/weight 593*410*381mm/27.5KG Product Description
